S10L Plain Lever Safety Rellief Valve
low lift safety relief valve, With lelver metal to metal seated/soft seal connection end acc. to NPT/BSP thread
online service
Safety Relief Valves, angle type
low lift safety relief valve, With lelver
metal to metal seated/soft seal
connection end acc. to NPT/BSP thread
Applications:
Provided as safety device for protection against excessive pressure in pressure vessels.
Approved for gases, vapours and fluids.
Working temperatures: -45℃~185℃
Working pressure: 0.3-25 bar
Standards Compliance:
Design and Manufacture: GB/T 12241-2005, GB/T 12243-2005
Face to Face(end to end): JB/T 2203-1999
Test and Inspection: GB/T 12243-2005
Material for main parts
NO
Name of part
Material
1
Cap
Brass
2
Lever
St. St.
3
Adjust Screw
Brass
4
Nut
Brass
5
Gasket
PTFE
6
Body
Brass
7
Spring
50CrVA
8
Spring Seat
Brass
9
Disc
Brass
10
Valve Seat
Brass
Main Dimension
Essential:
Valves are delivered at a set pressure, therefore when ordering
TS
Safety accessory and Safety protection device
please confirm set pressure, medium and temperature
Manufacture License of Special Equipment, People's republic of China
